119
The relevant parameters are described in Table 1-36:
RAID levels, which determine logical disk performance, fault tolerance, and
capacity.
Select the member disks that make up the RAID. The available disks are displayed
below the Select Disks column. Press Enter to select the disk. [X] indicates that
the disk has been selected.
Stripe size, the size of the stripe data blocks written on each disk.
The capacity of the logical disk.
Table 1- 36
After the RAID is created, it will be displayed under the RAID Volumes directory. Select a RAID and
press Enter to view the detailed information of the RAID (including RAID name, level, and disk information,
etc.).
Configure Hot Spare Disk
1. As shown in Figure 6-8, select the disk to be configured as a hot spare, and press Enter.
Figure 6-8 Selecting a disk to configure as a hot spare
Figure 6-8
2. Enter the interface shown in Figure 6-9, select "Mark as Spare", and press Enter.
Figure 6-9 Hot spare disk configuration interface
