Gooxi SL201-D08R-G3 User Manual

13
hot-swap SATA/SAS HDDs, and the rear upper layer is optional and supports 2*
2×3.5 inch SAS/SATA or 2* 2×2.5 inch SAS/SATA or NVME hot-swap hard
drives.
External port
Front port: 2 USB3.0, 1 VGA port
Rear: 1 VGA, 1 DB-9COM port, 2 USB3.0, 1 RJ45 Gigabit management LAN
port, 2* Gigabit/10 Gigabit RJ45 network ports
BMC
ASPEED AST2500
PCIe expansion
Support 2 PCIe 4.0 x32 slots (can be converted into various types of PCIE slots
through PCEI adapter board) , 1 PCIe 4.0 x16, 1 OCP 3.0 (PCIe3.0 x8 signal), 2
Slimline (PCIe4.0 x8 Signal)
TPM
Support
Power supply
Power supply
Platinum 550W, 800W, 1200W, 1600W , 2200W hot-swap redundant power
supply (adapt according to actual power)
System fan
Fan
Support 4* 8038 fans (optional 4* 8056 fans)
Remote management
BMC chip
ASPEED AST2500
IPMI Compliant
IPMI2.0
Management port
1 dedicated RJ45 management network port
System depth
System depth 748MM.
Option Family Support List
System
CentOS 7.5/7.6/8.0/8.1
RHEL 7.4/7.5/7.6/8.0/8.1
SLES12 SP3/SP4
Ubuntu 18.04 / Ubuntu-20.04-
Fedora 28
Windows 10
Win server 2012 R2/2016/2019
Xenserver 7.1/ 7.2/
ESXi 6.7/ 7.0U1c
Windows Server 2012 2016 Hyper-V
BIOS
Name
AMI
Support start mode
HDD (internal)/CD/USB/PXE
TPM support
Yes
Safety certificate
Nation
Asia, Europe, Americas, Australia, Africa
Energy saving
certification
CECP, CELP
Safety certificate
CCC, CE, FCC
RoHS
Meet the requirements
Environmental parameters
Operating
temperature
5 ℃ ~ 40 ℃

Gooxi SL201-D08R-G3 Specifications

General

Brand	Gooxi
Model	SL201-D08R-G3
Category	Server
Language	English
