GRAVOGRAPH M20 - Machine Views and Controls

17
M_M20 series_EN_C
G. Description of the machine
1. M20 / M20 ABC: front view of the machine
 Engraving table
1
2
3
4
5
6
7
8
9
10
11
12
1. Protective cover
2. Toolholderassembly
3. Penattachmenttailstock
4. Jig(s)
5. Vice
6. Penattachmentchuck(optionavailableonmachinesM20only)
7. Jawopeningandclosingadjustmentknob
8. Spindle pressure adjustment button (4 position(s))
9. Frame
10. Accessories drawer
11. Controlpanel(9-key󰘱exiblekeypad)
12. General stop button
