Using the machine
4. Insert the cutter into the spindle until it comes into contact with the material to be engraved. In
order to facilitate the passage of the cutter, slightly loosen the screw on the upper part of the cutter
button.
Carbide cutters are fragile.
Program0.5mm(0.020in)toadepthof1mm(0.039in)inordertocompensateforany󰘱atnessdefectsin
the plate.
5. Tightentheupperscrewofthecutterbuttoninordertoimmobilizeit,usingthefollowingwrench:
- driver (2 mm (0.079 in))
5. Setting the origin of the tool carrier (function not available for the M20 PIX
machine)
 M20 / M20 BEAUTY CUBE / M20 JEWEL
StorethepositionoftheZzeropointbypressingthe"Check"keyfor3seconds.Themachineemits
an audible signal.
The tool holder is raised.
 M20 ABC
Storethepositionofthetoolcarrierbypressingthe"Check"key.Themachineemitsanaudiblesignal.
The tool holder is raised.
Thefollowingmessageisdisplayed:
