Using the machine
2. Positioning the object to be engraved
1. Choosethejigsaccordingtothelengthoftheobjecttobeengraved.ConsultaGravotechretailer
to󰄈ndoutaboutthevariousjigsavailable.
The length of the object to be engraved must never exceed that of the jigs:
Jig(s)
M20JEWEL:choosejewelryjigsorplasticjigsaccordingtotheobjecttobeengravedandthelengthofthe
plate.
Jewelryjigs Plastic jigs
2. Choosetheappropriatesideofthejigaccordingtotheobjecttobeengravedorthethicknessof
the plate.
Theplatemustbeslightlyhigherthanthejigsinordertopreventtheregulatingnosefromstrikingthejig:
Jig(s)
