GRAVOGRAPH M20 - X84; Movement Speed; X84; M20 JEWEL (Wedding Ring Engraving); Noise Emission of the Machine (ISO 11201 Standard); Electrical Characteristics

64
M_M20 series_EN_C
Technicalspeci󰘰cations
 Movement speed
Axis
For all machines
Movementspeed:noload(maximum) X,Y 50 mm (1.969 in)/s
Z 40 mm (1.575 in)/s
Movementspeed:engraving(maximum) X,Y 25 mm (0.984 in)/s
Z 40 mm (1.575 in)/s
Movementspeed:diamondengraving
(maximum)
X,Y 35 mm (1.378 in)/s
Z 40 mm (1.575 in)/s
Speedofacceleration:engraving(maximum) X,Y 1000 mm (39.370 in)/s²
Z 1000 mm (39.370 in)/s²
Speedofacceleration:PIXmode(maximum) X,Y 5000 mm (196.850 in)/s²
Z 15000 mm (590.550 in)/s²
Repeatability - < 0.05 mm (0.002 in)
 M20 JEWEL (wedding ring engraving)
Internal diameter (minimum - maximum)
Width (maximum)
12.5 mm (0.492 in) - 24 mm (0.945 in)
9 mm (0.354 in)
Forinteriorclamping:
External diameter (minimum - maximum)
Width (maximum)
12.5 mm (0.492 in) - 27 mm (1.063 in)
18 mm (0.709 in)
For exterior clamping (plain band wedding
ring):
External diameter (minimum - maximum)
Width (maximum)
12.5 mm (0.492 in) - 26 mm (1.024 in)
18 mm (0.709 in)
3. Noise emission of the machine (ISO 11201 standard)
L
Aeq
- when awaiting engraving 51dB(A)+/-1
L
Aeq
- during nominal engraving 69dB(A)+/-2
L
pc
peak - Peak at rated engraving < 89 dB (C)
4. Electrical characteristics
Electronics Integrated
Nominal voltage / Type of current
Externalpowersupplyunit
Input:AC100-240V
Output:24V
Absorbed current Maximum: 1.7 - 0.75 A
Frequency
50-60Hz
Absorbed power 180 W
Protection(s) -
