GRAVOGRAPH M20 - M20 JEWEL Specific Operations

43
M_M20 series_EN_C
Using the machine
 M20JEWEL:positioningaweddingringonthechuck
Always remove the vice before changing to wedding ring engraving mode.
Alwaysraisethediamondholdertotheraisedpositionbeforechangingto󰄉atengraving
mode.
1
2
1. Allenkey(4mm(0.157in))
2. Screw
1. Open the machine protection cover.
2. Remove the vice, loosening the screw without removing it, using the wrench.
