Using the machine
1
2
3
1. Tailstock
2. Thumbwheel
3. Lockingbutton
4. Holdtheobjecthorizontallyandslidethetailstockbypressingthelockingbutton.
Engagetheobjectsuchthatitisheldsecurelybytheconeorthetailstock.
5. Lock the tailstock mount by releasing the locking button.
6. Adjusttheclampingwiththethumbwheelifnecessary.
