GRAVOGRAPH M20 - X84; Indicator Light Function

27
M_M20 series_EN_C
Description of the machine
+
Adjustment: machine (X, Y)
+
Adjustment: machine (Z)
+
Continuouscycle
Shift
+
Rotationofthespindle(On/O󰘯)
(function not available for the M20 PIX machine)
Shift
+
Automatic ZRef.
Shift
+
Positioningpointer(On/O󰘯)
 Indicator light function
1
2
1. Indicator light on = machine powered on
2. Indicator light on = travel of the Z axis
