GRAVOGRAPH M20 - Engraving Characteristics

63
M_M20 series_EN_C
Technicalspeci󰘰cations
2. Engraving characteristics
M20 / M20 JEWEL / M20 ABC
M20 BEAUTY
CUBE
M20 PIX
Opening the vice (maximum) 105 mm (4.134 in)
Passage under spindle Z (maximum) 40 mm (1.575 in)
100 mm
(3.937 in)
40 mm
(1.575 in)
PassageunderspindleZ:withjigs+
standard nose (maximum)
18mm(0.709in)-scaledknobfully
tightened
78 mm
(3.071 in)
-
PassageunderspindleZ:withjigs-no
nose (maximum)
25mm(0.984in)-scaledknobfully
tightened
85 mm
(3.346 in)
-
PassageunderspindleZ(total):standard
nose (maximum)
38 mm (1.496 in)
98 mm
(3.858 in)
-
PassageunderspindleZ(total):nonose
(maximum)
45 mm (1.772 in)
105 mm
(4.134 in)
-
AutomaticadjustmentoftheZorigin
(automatic ZRef.)
Yes
Red pointer Laser diode
Engraving precision along XY (maximum) < 0.1 mm (0.004 in)
Type of spindle(s) Rotating spindle / through spindle with cutter button -
Diameter (tool) 3.17 mm (0.125 in) -
Speed of rotation (maximum) 19200 rpm -
Power 20 W -
Depth regulating nose
Compatible with all the depth regulating noses
Gravograph
-
