Description of the machine
 M20 ABC: Touch Pad (rear view)
1 2 3 4
5 6 7
1. Touch screen pen
2. SD card connector
3. USBconnector-USBexternalkeyboard(notsupplied)
4. Connector
5. On/O󰘯switch
6. USB connector - Connection with the machine
7. Powersupply
6. Control panel
Start Engraving start
Pause Markingsuspended
"Check"key
Z Activation/deactivation of Z axis travel
Joystick Head movement (X, Y, Z)
Shift
Shift
