 M20 / M20 JEWEL (optional): positioning a pen on the pen attachment
Alwaysremovethejigsandopenthevicetothefullestextentbeforechangingtopen
attachment mode.
Checkthattheobjectisclampedsuchthatitcannotbeejectedduringengraving.
Check thatthe locking button and the thumb wheel are 󰄈rmly securing the elements
before starting work.
1
2
3
4
1. Jig(s)
2. Right hand cone
3. Chuck(optional)
4. Jawopeningandclosingadjustmentknob
1. Removethejigsfromthevice.
2. Openthevicetothefullestextentusingthejawopeningandclosingknob.
3. Placetheobjectagainsttherighthandconeorsecureitinthechuck.
