Connections - Installation
4. Installation
 Switching on the machine
1. Machine:placetheswitchinthe"I"position(On).
The machine emits an audible signal.
The power LED lights up.
2. M20ABC:switchontheTouchPadbypressingandholdingtheStart/Stopbutton.
Always switch on the machine before starting up the Touch Pad.
Leave the machine powered on, even if it is only going to be used at intervals.
 Resolution of the problems
If the machine does not switch on:
• checkthatthepowercordiscorrectlypluggedintoboththemachineandthepowersupply.
• checkthatthereispowertothemainsplug.
If the machine emits a long beep followed by a short beep and there is no movement,
call a Gravotech technician.
