Preventive maintenance
3. M20JEWELmachine(s)only
 Changing the diamond tip
1
3
2
4
2
1. Half󰘱at
2. Screw (a spare screw is supplied with the machine)
3. Diamond point
4. Allenkey(1.5mm(0.059in))
1. Loosen the screw with the wrench. Remove the diamond tip.
2. Place the new diamond tip in position. Tighten the screw with the wrench.
3. Adjustthemachineforweddingringengraving.
