Grove RT9130E - Page 121

Published 08-25-09, Control # 077-04 2-81
RT9130E SERVICE MANUAL HYDRAULIC SYSTEM
2
GROVE
FIGURE 2-46
12
11
2
1
10
5
4
7
13
3
6
8
14
9
7282
8
Item Description
1Barrel
2Rod
3Piston
4 Head
5 Spacer
6Nut
7 Piston Seal
8 Wear Ring
Item Description
9O-ring
10 O-ring
11 Backup Ring
12 Rod Seal
13 Wiper Ring
14 Wear Ring
15 Grease Cap
