LUBRICATION RT9130E SERVICE MANUAL
9-10 Published 08-25-09, Control # 077-04
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Drive Train (continued)
23
Coolant Strainer
(Cab Heater)
Figure 9-4 --- ---
Clean strainer screen
after first 100 hours and
every 2000 hours or 12
months thereafter.
Close shutoff valves.
Unscrew hex plug to
clean filter.
24 Air Cleaner Filter Figure 9-4 --- ---
• Replace filter
element when
indicator shows red
(25” H20).
• View indicator
through grill from rear
of crane.
Located in front of
fuel tank.
Refer to Service
Manual
25a
25b
Water Separator
Fuel Filter
Figure 9-4 --- ---
• Drain water trap
every 10 hours or
daily.
• Change filter every
500 hours or 6
months.
Primary fuel/water
separator is located
beside the fuel tank
26a
26b
Driveline - Slip
Joints
Figure 9-4
EP-MPG
Extreme
Pressure
Multipurpose
Grease
A6-829-003477
Until
grease
extrudes
500 hours or 3 months 3 grease fittings
27
Retarder
(Optional)
Figure 9-4 --- --- After 2000 hours
Grease using hand
grease gun
NOTE: Grease using hand grease gun until grease comes out of vent tube outlet located near grease nipple.
CAUTION: DO NOT OVER GREASE.
