LUBRICATION RT9130E SERVICE MANUAL
9-20 Published 08-25-09, Control # 077-04
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Boom (continued)
Crane Setup for Items 76, 77, 78: Crane to be set up on firm level surface with fully extended outriggers and 40,000 lbs
counterweight installed. Ensure the crane is level. Boom must be directly over the front and the house lock engaged. Set
boom angle at zero degrees. No load is permitted on the boom. The weight of the hookblock, overhaul ball and rigging must
not be supported by the boom. Do not extend the boom until the weight of these components is totally removed from the
boom.
76
Boom Section
Upper and Lower
Wear Pads
Figure 9-9
EP-MPG
Extreme Pressure
Multipurpose
Grease
A6-829-003477
Thoroughly
coat all
areas the
wear pad
moves on
50 hours or 1 week 12 places by brush
NOTE:
See Table 9-1, page 9-28 at the end of this sections for how to access lubrication points 76, 77, 78
77
Extend Cable
Sheaves
Figure 9-9
EP-MPG
Extreme Pressure
Multipurpose
Grease
A6-829-003477
Until
grease
extrudes
250 hours or 3
months
1 grease fitting
78
Retract Cable
Sheaves
Figure 9-9
EP-MPG
Extreme Pressure
Multipurpose
Grease
A6-829-003477
Until
grease
extrudes
250 hours or 3
months
2 grease fittings
(1) on each side
