Grove RT9130E - Page 127

Published 08-25-09, Control # 077-04 2-87
RT9130E SERVICE MANUAL HYDRAULIC SYSTEM
2
GROVE
FIGURE 2-50
6722
11
10
7
6
5
4
3
8
9
2
1
Item Description
1 Barrel
2Rod
3 Head
4Piston
5Nut
6O-ring
Item Description
7 Piston Seal
8O-ring
9 Backup Ring
10 Rod Seal
11 Wiper Ring
