Grove RT9130E - Page 163

Published 08-25-09, Control # 077-04 4-11
RT9130E SERVICE MANUAL BOOM
4
GROVE
Rear View of Boom
Item Description
54 Upper Telescope Cylinder
55 Wear Pad
56 Pusher
57 Cam Operated Valve
58 Manifold Block Adapters
59 Lower Telescope Cylinder
Item Description
60 Cam Operated Valve
61 Threaded Rod
62 Tapered Bar
63 Wear Pad
64 Grease Fitting
65 Wear Pad
66 Adapters
6084-2
FIGURE 4-2 continued
65
65
64
64
63
59
60
58
57
61
62
66
56
55
54
