Grove RT9130E - Page 181

Published 08-25-09, Control # 077-04 4-29
RT9130E SERVICE MANUAL BOOM
4
GROVE
FIGURE 4-4
5
4
3
2
1
6
7
8
9
10
13
11 14
12
Hose Reel Alignment
15
2.2 mm
(0.09 inches)
2.2 mm
(0.09 inches)
6693
Item Description
1 Sprocket
2 Bearing
3Brake
4 Clevis Pin
5 Brake mount
6 Cotter Pin
7 Boot
8 Housing
Item Description
9Bearing
10 Swivel Joint
11 Hose Reel
12 Disk
13 Chain
14 Orbit Motor
15 Shims
