BOOM RT9130E SERVICE MANUAL
4-34 Published 08-25-09, Control # 077-04
Cutaway For
Clarity
Top of
Boom
See Detail B For
Removal Kit
Cutaway For Clarity
Detail A
FIGURE 4-5
4
9
6, 7
5
3
8
1, 2
Lower Lift Cylinder Installation
Upper Lift Cylinder Installation
