RT9130E SERVICE MANUAL HOIST AND COUNTERWEIGHT
5
GROVE
Single Axis
Controller
Control Lever
Handle
Button
Thumb Thumper
Rotation Indicator
Soleniod12±2 Ohms
Control Module - CPU
Green LED
Amber LED
Red LED
To Thumb Thumper
High Speed
Solenoid
Sensor
Control Module - CPU
Control Module - CPU
Sensor
FIGURE 5-6
