Grove RT9130E - Page 300

8-10 Published 08-25-09, Control # 077-04
UNDERCARRIAGE RT9130E SERVICE MANUAL
FIGURE 8-3
1
2
3
4
2
4
2
Item Description
1 Carrier Frame
2 Pivot Point
Item Description
3 Fifth Wheel
4 Oscillation Lockout Cylinder
REAR AXLE
FIGURE 8-4
LH
RH
Axle Lockout Valve
Lockout Cylinders
Pump Supply
