Grove RT9130E - Page 58

2-18 Published 08-25-09, Control # 077-04
HYDRAULIC SYSTEM RT9130E SERVICE MANUAL
FIGURE 2-6
5
2
3
1
4
7
8
6
7283-2
7283-1
9
10
9
Item Description
1 Hydraulic Pump No. 1
2 Section No. 1 (Pump No. 1)
3 Section No. 2 (Pump No. 1)
4 Hydraulic Pump No. 2
5 Torque Converter
Item Description
6 Hydraulic Pump No. 3
7 Section No. 2 (Pump No. 3)
8 Section No. 1 (Pump No. 3)
9 Engine
10 Pump No. 4
