User Manual
13
Imaging performance
• Display 256-level gray and color thermal image on both VGA LCD screen and viewfinder
• Display true color visual image on both VGA LCD screen and OLED viewfinder
• Output both thermal and visual video to other display devices (e.g. VGA display or TV set)
• Transfer live thermal video into PC via USB cable
• Continuously zoom in or out thermal image from x1 to x10
• Auto or motorized focusing of IR lens
Temperature measurement
• Auto calibration ensures high accuracy
• Auto hot-spot tracing and center-cursor temperature measurement pinpoint the problem
• Up to 8 spots can be analyzed simultaneously in live or zoomed or frozen or saved images
• Up to 8 areas can be analyzed simultaneously in live or zoomed or frozen or saved images,
showing respective Max, Min or Average temperature within each area
• Line analysis can be done in live or zoomed or frozen or saved images; line profile can be
switched into horizontal or vertical coordinates system
• Histogram analysis can be done in live or zoomed or frozen or saved images
• Isotherm analysis can be done in live or zoomed or frozen or saved images
Image Storage
• Live images can be frozen to be static images to do multiple-spot analysis, multiple-area
analysis, line analysis and isotherm analysis
• Frozen images, comprising radiometric data, infrared image, visual image, voice
annotation and text annotation, can be saved into 2GB SD card or the built-in flash
memory in standard JPEG format
• Up to 30-second digital clip of voice can be recorded and saved for each image
