User Manual
27
change their respective values.
Button F1: Sleep mode
Pressing button F1 in the normal working mode can switch to sleep mode, in which all the
video outputs are turned off and the red indicator light at the back of the camera flickers.
Pressing it in sleep mode can switch into the normal working mode, in which the red indicator
light at the back of the camera shine steady.
Button F2: Thermal & visual image switch
Pressing button F2 in live, zoomed, frozen or saved thermal images can switch to visual
image. Vice versa.
Button F3: Laser locater/ Histogram control
When option Laser in sub-menu Function of menu Parameter is set as On, press button F3 in
live/zoomed thermal image to turn on the laser locater and press it again to turn off the laser
locater.
When option Histogram in sub-menu Function of menu Parameter is set as On, press button
F3 in frozen or saved thermal image to display or close histogram
Button F4: Auto focusing control
When there is no menu or dialog box in live/zoomed thermal image, keep button F4
depressed till a frame appears in the image, aim the frame at the target to be focused and
then release button F4, then the camera will automatically focus till getting a clear image of
the target.
