User Manual
26
and close the box.
When an option in the toolbar is highlighted, press the joystick to select this option and
execute the command corresponding to it.
Button S: Freeze & save control, option switch
Press button S to freeze a live/zoomed thermal image and press it again to save it into the
built-in flash memory or SD memory card.
Press button S to toggle between the 8 spots and 8 areas while doing spot and area analysis
on live or frozen or saved thermal images
Press button S to switch between horizontal and vertical coordinate systems when doing line
analysis on live or frozen or saved thermal images
Press button S to switch between options or buttons in menus or dialog boxes
Button C: Cancel
Press button C to cancel a dialog box or menu and return to the live/zoomed thermal image
When there is no menu or dialog box in live/zoomed thermal image, keep it depressed and
then press button S to perform a non-uniformity calibration.
Button A: Temperature range, filter & palette control
When there is no menu displayed in live/zoomed thermal image, keep button A depressed for
2 seconds and then release it to switch between its three modes Auto1, Auto2 and Manual,
with the corresponding prompt “Auto1” or “Auto2” or “Manual” shown in the status bar at the
left bottom of the image. Brightness and contrast of the image are controlled automatically in
the two auto modes and can be adjusted manually in manual mode.
When there is no menu displayed in live/zoomed thermal image, press button A for an instant
to select the temperature setup menu at the right side of the image. Move the joystick up or
down to toggle between its options Tmax, palette, Tmin and filter range, move it left or right to
