User Manual
89
the centre cursor up or down to measure temperature.
y While the main menu is displayed, press them to toggle between different sub-menus.
y In the temperature setup menu, press them to toggle between Tmax, palette, Tmin and
filter range.
y When there is a dialog box displayed in thermal image, press them to alter values of
different parameters.
y While doing spot, area and line analysis, press them to move the spots or areas or
starting/ending point of the line up or down and also change the size of areas.
y While doing isotherm analysis, press them to set the maximum temperature of the
isotherm band
Left and Right Buttons:
y Functions are the same as moving the joystick up and down
y When there is no menu displayed in live thermal image, pressing them to zoom in or out
the image continuously.
y While the main menu is displayed, press them to toggle between different options under
sub-menus.
y When there is no menu displayed in frozen or saved thermal image, press them to move
the centre cursor left or right to measure temperature.
y In the temperature setup menu, press them to change the values of Tmax, palette, Tmin
or filter range.
y When there is a dialog box displayed in thermal image, press them to toggle between
digits of parameter values.
y While doing spot, area and line analysis, press them to move the spots or areas or
starting/ending point of the line to left or right and also change the size of areas.
y While doing isotherm analysis, press them to set the minimum temperature of the
isotherm band
