User Manual
76
• Adjust the TV video display device to receive PAL or NTSC video as per the above setup
• Now you can view live VGA video on LCD screen & OLED viewfinder and live PAL or
NTSC video on the TV video display device simultaneously
Note:
• It is also feasible to connect the camera to a VGA display device and a TV video display
device simultaneously, through the corresponding VGA cable and RS232/ TV video cable
• Set sub-option VideoOut in option System under submenu Parameters to be PAL or NTSC,
save the setup and return to live image
• Now you can view synchronous video output on the LCD screen & OLED viewfinder of the
camera, the VGA display device and the TV video display device. The TV video display
device displays PAL or NTSC video, and the left display VGA video.
Transferring Data from the Camera to PC
• Before transferring data from the ThermoPro
TM
TP8 camera to PC, ensure that the
PC offers USB2.0 interface and the USB driver for the camera has been
successfully installed in the PC.
• To transfer data saved in the SD card to PC, get the SD card out of the camera, insert it
into the card reader and then insert the reader to a USB2.0 interface of the PC. Then PC
will identify the card as a removable hard disk. With the help of corresponding menu
commands in Guide IrAnalyser
®
software, you can copy the saved data to PC or delete
them from the card and etc.
• You can also format the SD card when connecting it to PC through the card reader but not
running the corresponding menu commands in Guide IrAnalyser
®
software.
Note: To format the SD card, choose FAT32 as the file system.
