2. InformatIon
Rail combinations in room-covering systems
Underhanging traverse rail
D. Mini parallel rails with
underhanging mini traverse rail
An underhanging traverse rail is used:
• When it is impossible to mount the traverse rail between
the parallel rails, because lamps, smoke alarms or
similar equipment have been installed on the ceiling.
• When two rail systems are to be combined.
• When the traverse and parallel rails cannot be of equal
height.
E. Mini parallel rails with
underhanging maxi traverse rail
F. Mini parallel rails with
underhanging jumbo traverse rail
