Switch tracks and turntable
Switch tracks must be installed in places where it is neces-
sary to lead the rail in different directions. The switch tracks
are operated either manually or electrically.
A turntable must be installed in places where two rails
cross each other. The turntable is electrically operated.
The switch tracks shown are 60º and 90º right.
