3. InstallatIon
Fixing wall brackets
Construction Rail type Fixing
FISCHER
Number Remarks
Concrete
B25 (C20/25)
Mini, Midi,
Maxi &
Jumbo
Zykon impact anchor FZEA II 12/40
Concrete screw FBS
Expansion anchor FAZ
2 hv = 60 mm (2
3
/
8
")
Solid/cellular bricks Mini, Midi,
Maxi &
Jumbo
FIS V 360 S+ M10 x 110 mm (4
5
/
16
")
Threaded rod (5.8)
2 hv = 75 mm (3")
Solid lime sand
bricks
Mini, Midi,
Maxi &
Jumbo
FIS V 360 S+ M10 x 110 mm (4
5
/
16
")
Threaded rod (5.8)
2 hv = 75 mm (3")
Hollow bricks Mini, Midi,
Maxi &
Jumbo
FIS V 360 S + M10 x 130 mm (5
5
/
16
")
Threaded rod (5.8) + mesh screen FIS
H 20 x 85 N
2 hv = 75 mm (3")
Hollow brick blocks Mini, Midi,
Maxi &
Jumbo
FIS V 360 S + M10 x 130 mm (5
5
/
16
")
Threaded rod (5.8) + mesh screen FIS
H 20 x 85 N
2 hv = 75 mm (3")
Leca/Fibo elements
>7,5 MPa/1500
kg/m
3
Mini, Midi,
Maxi &
Jumbo
FIS V 360 S+ M10 x 110 mm (4
5
/
16
")
Threaded rod (5.8)
2 hv = 75 mm (3")
Aerated concrete Mini, Midi,
Maxi &
Jumbo
FIS V 360 S + M10 x 110 mm (4
5
/
16
")
Threaded rod (5.8) + cone drill
PBB + centering ring PBZ
2 hv = 75 mm (3")
Plaster board
2 x 13 mm (
1
/
2
")
Mini, Midi,
Maxi &
Jumbo
HM 5 x 65 S 4 Plaster board brackets
must be used
Plaster board
1 x 13 mm (
1
/
2
")
Mini, Midi,
Maxi &
Jumbo
HM 5 x 52 S In all
predrilled
holes
Floor posts must be used
Fixing wall brackets GH2/GH2 HD max 3,75 kN:
hv = minimum anchoring depth
