Guldmann GH2 - Combinations of Rail Curves

90°
60°
45°
30°
1000 mm
40"
500 mm 20"
293 mm
11
3
/
4
"
134 mm
5
3
/
8
"
© Guldmann GB-1394/11/08
34
2. InformatIon
Combinations of rail curves
There are many possible combinations of rail curves.
All standard curves end in a 500 mm (20") straight rail.
The dimensions given are absolutely minimum dimensions.
