Guldmann GH2 - Fixing Ceiling Brackets Fischer

© Guldmann GB-1394/11/08
42
3. InstallatIon
Fixing ceiling brackets
Fixing ceiling brackets GH2/GH2 HD max 3,75 kN:
Construction Rail type Fixing
FISCHER
Number Remarks
Beton B25
(C20/25)
Mini, Midi,
Maxi &
Jumbo
Zykon impact anchor FZEA II 12/40
Concrete screw FBS
Expansion anchor FAZ
Min. 1 hv = 60mm (2
3
/
8
")
Concrete/hollow floor
divider
Mini, Midi,
Maxi &
Jumbo
FIS V 360 S + M10 x 130 mm/ (5
3
/
16
")
Threaded rod (5.8) + mesh
H 20 x 85 N
2 Depending on type of floor
divider (holes in floor
divider) hv = 75 mm (3")
Bauma- / R Mini, Midi,
Maxi &
Jumbo
FIS V 360 S+ M10 x 130 mm (5
3
/
16
")
Threaded rod (5.8) + mesh
H 20 x 85 N
2 hv = 75 mm (3")
Hollow bricks Mini, Midi,
Maxi &
Jumbo
FIS V 360 S + M10 x 130 mm (5
3
/
16
")
Threaded rod (5.8) + cone drill
PBB
2 or 4 Minimum floor divider
thickness 150 mm (6")
hv = 75 mm (3")
Hollow brick blocks Mini, Midi,
Maxi &
Jumbo
FIS V 360 S + M10 x 130 mm (5
3
/
16
")
Threaded rod (5.8) + cone drill
PBB
2 Minimum floor divider
thickness 150 mm (6")
hv = 75 mm (3")
Leca/Fibo elements
>7,5 MPa/1500
kg/m
3
Mini, Midi,
Maxi &
Jumbo
FIS V 360 S + M10 x 130 mm (5
3
/
16
")
Threaded rod (5.8) + cone drill
PBB
2 Minimum floor divider
thickness 150 mm (6")
hv = 75 mm (3")
hv = minimum anchoring depth
* Ceilings made of “Bauma” or “Romadæk” must
be load tested on site as no unambiguous test
reports are available.
** This also applies to lightweight aggregate clinker
floor dividers as these are manufactured with different
compression strengths and densities.
*** A cone drill must be used on light clinker floor dividers
due to tension zones.
