Guldmann GH2 - Underhanging Traverse Rail

209 mm
8
3
/
8
"
97 mm
3
7
/
8
"
269 mm
10
3
/
4
"
231 mm
9
1
/
4
"
165 mm
6
9
/
16
"
291 mm
11
9
/
16
"
276 mm 11"
165 mm
6
9
/
16
"
336 mm
11
3
/
8
"
© Guldmann GB-1394/11/08
31
2. InformatIon
Rail combinations in combined systems
– underhanging traverse rail
O. Mini parallel rails with under-
hanging jumbo traverse rail cut-down
for a combination system
P. Maxi parallel rails with under
-
hanging maxi traverse rail cut-down
for a combination system
Q. Maxi parallel rails with under
-
hanging jumbo traverse rail cut-down
for a combination system
