4. electrIcal connectIon
Combi-lock
CL3 manual
Installation of the Manual Combi-lock
Mount changeover mechanism on safety lock for fixed rail
with the accompanying screws.
Installing the safety lock on fixed rail
• The safety lock for the fixed rail and tongue are pushed
together into the T track in the Mini rail.
• The safety lock should be installed so that its edge is
flush with the front edge of the rail.
• Fasten the safety lock with two M4 x 10 mm locking
screws.
• Use the safety lock as a drill gauge and hold it precisely
in position while drilling. A screw clamp can also be
used to keep the safety lock in position while drilling.
Bottom of safety lock
must fit tightly against bottom of
rails.
• Drill the holes and make the M4 threads. Clean up com
-
ponents and mount the screws.
• Install bracket for Combi-lock. Before finally fastening
the bracket, check that the rail is level, both horizontally
and vertically. If necessary, adjust the bracket.
Installing the safety lock on traverse rail
• Loosen the M8 nuts in the T track plate so that the
safety lock can be pushed into the T track of the rail.
• The safety lock should be installed so that its edge is
flush with the front edge of the rail.
• When the safety lock has been correctly installed,
the two M8 nuts can be tightened.
• Check that the there is a space of minimum 1 mm
(
1
/
16
")
from the activation pin in the T track to the bottom of the
T track.
• Fasten the safety lock with one M4 x 10 mm locking
screw.
• Use the safety lock as a drill gauge.
• Drill the holes and make the M4 threads. Clean up
components and mount the screws.
Important
After installation has been completed, check that the locks
work in combination and that they open and close correctly
individually.
All parts have been lubricated from the factory.
Do not lubricate or grease any components or rails.
