GW Instek PSU Series User Manual

PSU Series User Manual
96
Falling current slew rate
F-07
0.001~2.000A/msec (PSU 6-200)
0.001~1.800A/msec (PSU 8-180)
0.001~1.200A/msec (PSU 12.5-120)
0.001~1.000A/msec (PSU 15-100)
0.001~0.760A/msec (PSU 20-76)
0.001~0.500A/msec (PSU 30-50)
0.001~0.380A/msec (PSU 40-38)
0.001~0.300A/msec (PSU 50-30)
0.001~0.250A/msec (PSU 60-25)
0.001~0.190A/msec (PSU 80-19)
0.001~0.150A/msec (PSU 100-15)
0.001~0.100A/msec (PSU 150-10)
0.001~0.025A/msec (PSU 300-5)
0.001~0.008A/msec (PSU 400-3.8)
0.001~0.006A/msec (PSU 600-2.6)
Internal resistance
setting
F-08
0~0.030Ω (PSU 6-200)
0~0.044Ω (PSU 8-180)
0~0.104Ω (PSU 12.5-120)
0~0.150Ω (PSU 15-100)
0~0.263Ω (PSU 20-76)
0~0.600Ω (PSU 30-50)
0~1.053Ω (PSU 40-38)
0~1.667Ω (PSU 50-30)
0~2.400Ω (PSU 60-25)
0~4.210Ω (PSU 80-19)
0~6.667Ω (PSU 100-15)
0~15.00Ω (PSU 150-10)
0~60.00Ω (PSU 300-5)
0~105.3Ω (PSU 400-3.8)
0~230.8Ω (PSU 600-2.6)
Bleeder circuit control
F-09
0 = OFF, 1 = ON, 2 = AUTO
Buzzer ON/OFF control
F-10
0 = OFF, 1 = ON
OCP Delay Time
F-12
0.1 ~ 2.0 sec
Current Setting Limit
(I-Limit)
F-13
0 = OFF, 1 = ON
Voltage Setting Limit
(V-Limit)
F-14
0 = OFF, 1 = ON
Display memory
parameter when recalling
(M1, M2, M3)
F-15
0 = OFF, 1 = ON
