We reserve the right to make changes of a technical nature 15
Information about the FWB, FWQ distribution board range
Cable strain relief
Large pipes and cables can be optionally fixed to the top and bottom of the FWB / FWQ cabinet with a cable
strain relief. The 100 mm long C profile rail FZ850S (30 x 15 x 2 mm) can be used at the top and bottom per 250 mm
panel width. The cable clamp can then be inserted in the C profile rail. Slot width: 16 mm.
Md
max
- 2 Nm
16
Fixing thick pipes to the plastic bottom part of the cabinet
