29 4000670450 E 04.19 USA / GB
3632T - HTT13
B
- Familiarization
Controls and indicators
Marking Description Function
1 Key Switch
• Turn the KEY SWITCH ( 1 ) to the GROUND ( 1b ) to select operation from the
ground control box.
• Turn the KEY SWITCH ( 1 ) to the PLATFORM ( 1a ) to select operation from the
platform control box.
• Turn the KEY SWITCH ( 1 ) to the off position . Power supply is now
switched off.
• Remove the key to protect against unauthorized operation.
2
Battery Condition
Indicator
Indicator LEDs light up to indicate the level of charge in the batteries :
• A lighted green LED indicates an adequate charge level.
• A lighted yellow LED indicates the need for charging soon.
• A lighted red LED warns that the battery charge level is low; all functional
operations become non-functional until the batteries are recharged.
3 - 4
Engine Start and Choke /
Glow Plug
1
• Start a cold engine by pressing (pushing) in and holding the CHOKE ( 4 ) button
then press (push) the ENGINE START ( 3 ) button. To start / restart a warm engine,
press (push) the ENGINE START ( 3 ) button only.
• Glow plug operation : Press (push) the GLOW PLUG ( 4 ) button and hold for 30 -
60 seconds then press (push) the ENGINE START ( 3 ) button
5 Display panel
The DISPLAY PANEL is a lighted text window that displays the current operating
status or an existing error condition when the KEY SWITCH ( 1 ) is positioned at
either(1a) or(1b).
6 Emergency stop button
• When pushed in, the EMERGENCY STOP ( 6 ) button disconnects electrical
power to the ground (lower) and platform (upper) control boxes
• The EMERGENCY STOP button should only be pressed (pushed) in to
immediately stop all aerial work platform motion.
• To resume control, “pull out” the EMERGENCY STOP ( 6 ).
7 - 8
Boom Extend / Retract
Buttons
• Pressing (pushing) in and holding a desired SPEED button ( 15 ) and the BOOM
EXTEND button ( 7 ) at the same time extends the telescopic boom.
• Pressing (pushing) in and holding a desired SPEED button ( 15 ), and the BOOM
RETRACT button 8 at the same time retracts the boom.
• Telescopic boom motion continues until the buttons are released, or until the
boom reaches a hard stop, or a safe travel limit.
9 - 10
Boom Raise / Down
Buttons
• Pressing (pushing) and holding a desired SPEED button ( 15 ) and the BOOM
RAISE button ( 9 ) at the same time will raise the boom.
• Pressing (pushing) and holding a desired SPEED button ( 15 ) and the BOOM
DOWN button ( 10 ) at the same time will lower the boom.
• Boom motion continues until the buttons are released or until each boom reaches
a hard stop or a safe travel limit.
11 - 12 Turret Rotation Buttons
• Pressing (pushing) and holding a desired SPEED ( 15 ) button, and the TURRET
ROTATION ( 11 ) button at the same time enables the turret to rotate in the
CLOCKWISE direction.
• Pressing (pushing) and holding a desired SPEED ( 15 ) button, and the TURRET
ROTATION ( 12 ) button at the same time enables the turret to rotate in the
COUNTER CLOCKWISE direction.
• The turret will rotate through 700° of Non-Continuous rotation until the buttons are
released or the stop is reached.
13 - 14 Platform Leveling Buttons
• Press (push) and hold any SPEED ( 15 ) button, and the desired PLATFORM
LEVELING UP ( 13 ) or PLATFORM LEVELING DOWN ( 14 ) button at the same
time to level the work platform.
• This levels the platform only, NOT the aerial work platform.
15 Speed buttons
• The SPEED ( 15 ) buttons are located along the lower right side of the control
panel, one of the speed buttons must be pressed (pushed) in and held while
selecting any boom function.
• There are four speeds that range from fast (RABBIT), to slow (TURTLE), available
to help control the positioning of the boom.
