30 4000670450 E 04.19 USA / GB
3632T - HTT13
B
- Familiarization
16 - 19 Outrigger controls
For simultaneous automatic outrigger extension / retraction of all four ( 3 )
outriggers :
• Select the EXTEND ( 16 ) button or RETRACT ( 17 ) button and the AUTO
LEVEL ( 18 ) button at the same time.
To individually extend or retract the outriggers :
• Select the EXTEND ( 16 ) button or RETRACT ( 17 ) button, and one of the four
OUTRIGGER ( 19 ) buttons at the same time.
• The outrigger indicator LEDs ( 20 ) lights up when the outriggers are properly
deployed and the aerial work platform weight is on the outrigger foot pads.
• Each of the outer outrigger LEDs indicates load is on the outrigger footpad.
• Each of the inner outrigger LEDs, when flashing, indicates that side is low and
needs to be further raised for leveling.
20 Boom Stowed LED
• When this LED is "FLASHING" it indicates that the booms are not in the "stowed"
position, and the outriggers cannot be operated (non-functional).
• When this LED is "ON SOLID" it indicates that the booms are in the "stowed"
position, and the outriggers can be operated (functional).
21 Power • The LED ( 27 ) lights up when power is On.
1. For machines with engines only
Marking Description Function
