39 4000670450 E 04.19 USA / GB
3632T - HTT13
B - Familiarization
Decal placement - Decal kit - ANSI/CSA/AS - 3632T - HTT13 -
Used on machines with serial numbers prior to 36T18-00015 only
Marking Color Description Quantity 3632T - HTT13
1Red
Decal - Danger - Main Instruction / Hazard -
Platform
1 B06-00-0471
2 Orange Decal - Warning - Read / Understand Manual 1
For ANSI : B06-00-0475
For AS : B06-00-0475-CE
3 Blue Decal - Notice - Operator Manual Missing 1 B06-00-0473
4 Blue Decal - Notice - AC Power 2
For ANSI : B06-00-0062
For AS : B06-00-0062-CE
5 Other Decal - Air - 120 PSI 2 B06-00-0530
6 Other Decal - Water - 3000 PSI 2 B06-00-0531
7 Blue Decal - Notice - Lanyard attachment 1 B06-00-0552
8 Other Decal - Flag, Made In USA 1 0202-0523
9Blue
Decal - Notice - Working area / Range of
motion
2 B06-00-0476
10 Blue Decal - Notice - Platform maximum load 1
For ANSI : B06-00-0474
For AS : B06-00-0474-CE
11 Orange Decal - Warning - Platform operation 1 B06-00-0491
12 Yellow Decal - Caution - Latch / Jack / Brake 1 B06-00-0493
13 Orange Decal - Warning - Unhitch To Operate 2 B06-00-0550
14 Orange Decal - Warning - Hand Pinch Point 16
For ANSI : B06-00-0405
For AS : B06-00-0405-CE
15 Red Decal - Danger - Tip Over Hazard 6 B06-00-0521
16 Orange Decal - Warning - Outrigger Crush Foot 8
For ANSI : B06-00-0404
For AS : B06-00-0404-CE
17 Red Decal - Danger - Electrocution 2
For ANSI : B06-00-0482
For AS : B06-00-0482-CE
18 Orange Decal - Lubricate Semi - Annually 1 B06-00-0037
19 Blue Decal - Notice - Emergency Lower 2 B06-00-0506
20 Orange Decal - Warning - Fork Lift Use 2 B06-00-0477
21 Orange Decal - Warning - Maximum Tow Speed 65 1 B06-00-0542
22 Yellow
Decal - Caution - Generator Plate Maximum
200
1 B06-00-0496
23 Blue Decal - Notice - AC Power Connection 1 B06-00-0478
24 Orange Decal - Warning - Crush hazard 2 B06-00-0543
25 Red
Decal - Danger - Main instruction / Hazard -
Base
1 B06-00-0505
26 Orange Decal - Warning - Ground operating 2 B06-00-0468
27 Red
Decal - Danger - Battery / Charger
instruction
1 B06-00-0484
28 Red Decal - Danger - Battery / Charger Safety 1
For ANSI : B06-00-0034
For AS : B06-00-0034-CE
29 Yellow Decal - Caution - Compartment access 2
For ANSI : B06-00-0495
For AS : B06-00-0495-CE
30 Blue Decal - Notice - Emergency hand pump 1 B06-00-0504
31 Blue Decal - Notice - Handle applications 1 B06-00-0503
32 Blue Decal - Notice - Low Foam Hyd Oil 1
For ANSI : B06-00-0068
For AS : B06-00-0068-CE
33 Blue Decal - Notice - Contains hazardous material 1 B06-00-0494
