Headsight TRUESIGHT 2 - Wheel Angle Sensor Parts

12
3
4
D C
B
E
F
G
H
D C
B
A
E
F
G
H
5
6
78
12
3
4
5
6
78
ITEM NUMBER PART NUMBER DESCRIPTION QUANTITY
1 08200157 10-24x1/2 SLOTTED WASHER HEAD HEX SCREW 2 2 HT2128 SENSOR 1
3 08100135 O-RING SIZE-021 1 4 08100132 RETAINING RING 1 5 HT2665 WHEEL ANGLE SENSOR BODY 1
6 08100138 O-RING SIZE-012 1 7 HT2703
HT2702
SHORT ARM, STANDARD
LONG ARM, CASE/IH 8010, X120 & X230
1
8 HT2503
HT2502
COMPLETE SENSOR, STANDARD COMPLETE SENSOR, CASE/IH 8010, X120, X230
HT2502_HT2503
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES DIMENSIONS W/O TOL ARE BASIC
DATE
FEB 20, 18
PROJECTION
THIRD ANGLE
SHEET 1 OF 1
THE INFORMATION CONTAINED ON THIS DRAWING IS PROPRIETARY TO HEADSIGHT, INC. ANY UNAUTHORIZED USE OF SUCH CONTENTS IS STRICTLY PROHIBITED. MATERIAL N/A DESCRIPTION WHEEL ANGLE SENSOR PARTS HT2502_HT2503
CHG LEVEL
C
02
TOLERANCE
x.x = ± .030
x.xx = ± .010
x.xxx = ± .005
ANGLES = ± 1/2°
NOTE: SENSOR CALIBRATION TARGET VOLTAGE WITH SENSOR CENTERED = 2.50V
1
2
3
4
5
6
7
55
Parts
