HEAT-TIMER CORP.
059305–00 REV. E
03 SPECIFICATIONS
ETV ASSEMBLY
DIMENSION
A B C D
½” 3
1
/ 8” 2” 10 ½” 2
3
/ 8”
¾” 3
1
/ 8” 2” 10
5
/ 8” 2
3
/ 8”
1” 4” 2
1
/ 8” 10
3
/ 4” 2
3
/ 8”
1 ¼” 4” 2 ½” 11” 2
3
/ 8”
1 ½” 4
4
/ 5” 2
4
/ 5” 11
3
/ 16” 2
3
/ 8”
2” 5 ½” 3
3
/ 8” 11
3
/ 8” 2
3
/ 8”
2 ½” 6
5
/ 16” 4” 11
3
/ 4” 2
3
/ 8”
MIXED
A
B
C
7 ¾”
4 ¾”
D
Maintain 12 inches
minimum
for servicing clearance
Maintain 18 inches minimum
for servicing clearance
Maintain 12 inches minimum
for servicing clearance
Maintain 12 inches minimum
for servicing clearance
Maintain 12 inches minimum for servicing clearance
HOT
COLD
ETV PLATINUM PLUS STAINLESS STEEL VALVE DIMENSIONAL
