heat-timer ETV Platinum Plus - ETV PLATINUM PLUS STAINLESS STEEL VALVE SIZING

059305–00 REV. E
HEAT-TIMER CORP.
|
9
03 SPECIFICATIONS
PRESSURE
DROP PSI
VALVE SIZE
½” ¾” 1” 1 ¼” 1 ½” 2” 2 ½”
Cv 5 7 12 18 29 46 73
3 8 12 20 32 50 80 126
4 9 15 23 37 58 93 145
5 10 16 26 41 64 103 162
6 12 18 28 45 71 113 178
7 13 20 31 50 78 125 192
8 14 21 33 53 83 132 205
9 15 22 35 56 88 140 218
10 16 23 36 58 91 145 230
11 17 24 38 62 97 154 241
12 18 25 40 64 100 160 252
BUILDING
RECIRC
5 GPM 10 GPM 15 GPM
GALLONS PER MINUTE
ETV
ASSEMBLY
VALVE CONNECTIONS—NPSC
HOT COLD MIXED
½” ½” ½” ½”
¾” ¾” ¾” ¾”
1” 1” 1” 1”
1 ¼” 1 ¼” 1 ¼” 1 ¼”
1 ½” 1 ½” 1 ½” 1 ½”
2” 2” 2” 2”
2 ½” 2 ½” 2 ½” 2 ½”
