heat-timer ETV Platinum Plus - 03 SPECIFICATIONS; ETV PLATINUM PLUS CONTROL MODULE; ETV PLATINUM PLUS ACTUATOR; ETV PLATINUM PLUS VALVE BODY

8
|
HEAT-TIMER CORP.
059305–00 REV. E
03 SPECIFICATIONS
ETV PLATINUM PLUS CONTROL MODULE
Voltage Input 120Vac 60Hz
Maximum Input Rating
48VA max
Dimensions (W x H x D)
11” x 9” x 3 ¾” (279.4mm x 228.6mm x 95.25mm)
Weight
2.5lbs (1.13kg)
Modes of Operation
ETV, HTLV, ETV + HTLV
ETV Setpoint
40°F to 200°F (4°C to 93°C)
Alarm Setpoint
40°F to 200°F (4°C to 93°C)
Modulation Output Signal
0–10V (default), 2–10V, 0–5V, 1–5V, 4–20mA
Output Relays
1 HTLV Lockout
1 Modem Reset
1 Valve Output
Output Relay Rating HTLV Lockout: 3A at 120Vac 60Hz
Modem Reset: 5A resistive at 120Vac 60Hz
Valve Output: 1A inductive at 120Vac 60Hz
Inputs System Temperature, Aux Temp 1 (Temp or Switch), Aux Temp 2 (Temp or Switch)
Flow Prove, Remote Setpoint (4–20mA)
User Interface
Digital Display
Display Units: Temperature (°F and °C)
Status Indicators (3 LEDs)
Variable-Function Buttons (4)
ETV PLATINUM PLUS ACTUATOR
Voltage Input
24Vac 60Hz
Power Consumption
18VA max
Input Signal
0–10V
Weight
2.6 lbs (1.2 kg)
ETV PLATINUM PLUS VALVE BODY
Body and Trim
304 Stainless Steel
Maximum Operating Temperature
300°F (149°C)
Maximum Working Pressure
225 psi
Stem Material
640 Stainless Steel
