ETV Platinum Plus Control Module Output Status LEDs The ETV Platinum Plus has three output status LEDs:
06 DISPLAY AND PROGRAMMING
LED DESCRIPTION
Actuator Signal Indicates the change in the mixing valve opening. Any time the ETV Platinum Plus changes the
valve opening, the LED will turn on for approximately one second. If the LED remains lit, the
control is sending the Actuator a “fully open” or “fully close” signal.
No Flow Indicates no flow exists when lit.
NOTE: This indicator is only applicable when using a Flow Switch as PROVE of flow in
applications without a building recirculation system.
HTLV Lockout
(High Temperature Limit)
Indicates the control is in lockout mode when lit. System temperature rises above
the Alarm Limit for the Trigger Delay period, or a sensor has been disconnected.
See “Alarm Messages” on page 42.
After the alarm condition has been corrected, the ETV Platinum Plus must be manually
reset to resume normal operation.
