HEIDENHAIN iTNC 530 HSCI Service Manual

26 – 434 HEIDENHAIN Service Manual iTNC 530 HSCI
26.8 Corrective action
Cleaning Use standard cleaning agents to clean transmitter/receiver units.
Realigning
the SE
If required, realign the transmitter/receiver unit.
Exchange of
components
If required, replace the (rechargeable) battery, the broken stylus (of TS), the damaged contact plate
(of TT), the defective cable, etc.
Recalibration Check the accuracy of the touch probe system after exchanging the stylus, the contact plate, and
of course after a collision. Perform a recalibration.
For this purpose, consult the machine operator, the machine manufacturer or your HEIDENHAIN
service agency.
Returning the
touch probe
Return defective touch probes and those that impair the function of the control for examination.
Returning
the control
component
If the touch probe interface of the PLB 62xx or UE 11x is defective, replace this component.
--> See ”Exchange of HEIDENHAIN components” on page 29 – 515
Note
A detailed description of the visual status check, of the beam direction, of battery exchange,
stylus exchange, centering, specifications, etc. can be found in the mounting instructions of the
touch probe!
Attention
When you exchange the battery, pay attention that the polarity is correct.
Attention
After the stylus (of TS) or the contact plate (of TS) has been exchanged, the touch probe must be
calibrated again.
Note
A detailed description of the visual status check, of the beam direction, of battery exchange,
stylus exchange, centering, specifications, etc. can be found in the mounting instructions of the
touch probe!
If required, follow the instructions of the machine manufacturer!
Note
A detailed description of the visual status check, of the beam direction, of battery exchange, stylus
exchange, centering, specifications, etc. can be found in the mounting instructions of the touch
probe!
If required, follow the instructions of the machine manufacturer!
Note
A TL Micro laser touch probe system must/should be recalibrated under the following conditions:
 For initial operation and after cleaning or adjustment
 Directly before precision measurements
