Figure 4-8
After the device normally starts up, the default setting is to preview in
multi-screen display mode. Products with different channels has different
amount of split screens to display. On the preview interface, you can set the
appropriate date and time. On the bottom left of the screen, it shows the
recording status of each video channel or alarm status icon.
The function of each icon is shown in the following table:
The monitoring channel is in video.
The monitoring channel is in the motion detection
state.
The monitoring channel is in the state of intelligent
alarm
Table 4-1
4.4 Quick add device
Quick add device is shown in Figure 4-9:
○
1
At the preview menu, for the channel of unconnected IP Camera, click
" " icon.
