Video Output Interface: NVR external monitor port.
Channel: Channel. Show all channels of the NVR for user configuration.
Picture Segmentation: According to the number of roads supported by
the NVR, there are generally single screen, 4 screens, 6 screens, 8
screens, 9 screens, 16 screens, and 36 screens.. Option.
Bind: Once clicked, the existing configuration can be bound to the
device video output port.
Unbind: Click to unbind the bound video output port.
NOTE
The number of monitors that can be accessed by different devices is
different, and the number of screen splits will be different. Please refer
to the actual one.
5.3.8 Maintenance
The Maintenance is compose of System Information, Upgarde, Network,
System Service, HDD Operation and Network Information, as shown in Figure
5-74 below.
Figure 5-74
5.3.8.1 System Information
The specific operation steps are as follows:
