bodily harm to those handling the unit. Always team lift the chassis by gripping the underside
of the unit, and never try to lift a chassis that is filled with drives.
Figure 141: Bearing Plate
Figure 142: Installing the Chassis
b)
Caution: Make sure that the bearing plate on the inside of the mid-rails are fully forward
and that the detent has engaged. This is to prevent potential damage due to improper mating
of the rails.
126
4 Part Replacement
User Guide 4.9 Chassis Replacement
